Multizone public address system description
◆ High integration level: integrates 11 modules into 1 device. These are: telephone input module,16 zones distribution matrix module, alarm input module, peripherals control module, MP3 player module, etc.
◆ High stability: use ISA port to improve the stability and reduce inside cable; high performance micro processor can work for a long time at very low power consumption
◆ Easy upgrade: add relative module to acquire more functions
◆ Easy extension: add one distribution matrix module to extend 16 zones
◆ Easy operation: 10 programmable shortcut keys for easy operation
◆ CAN bus line: use international standard CAN bus line to control peripherals, can transmit the data bidirectionally in long distance
◆ Various broadcasting modes for choice: telephone broadcasting, local broadcasting, remote paging, emergency broadcasting, etc.
◆ Powerful remote control function: can connect with max. 8 remote paging stations which is able to remote control other equipments.
◆ Fire protection linkage: with fire alarm input ports, can broadcast forcibly in emergency
◆ Group function: can divide various zones into groups, max. 64 zones for 1 group, max. 30 groups can be set
Features.
◆ Zone Distribution matrix, with built-in pre. Amplifiers for each zone.
◆ Standard configuration is 16 zones, 6+1 channels of audio sources input, zone is extendible
◆ Can control audio sources equipments (DVD,MP3, Tune) automatically or manually, as well as sequence controller
◆ Edit the programs on PC, then download to this device, or edit the programs on this device to fulfill auto-play function.
◆ Can edit 8 kinds of programs, each program up to 220 steps, with 7 kinds of weekly programs and 1 temporary program.
◆ Remote control station can control other equipments manually
◆ Connect with telephone input module, can broadcast remotely in zone/group/all zone mades
◆ With local broadcasting function, can broadcast in zone/group/all zone modes
◆ Built-in pre. Amplifier for each input audio source equipment
◆ With built-in 3 channels of programmable power output jack; 1 channel of programmable short-circuit output to trigger the sequence controller
◆ N±0/1/2/3/4/all zones fire alarm modes for choice
◆ 2 channels of short-circuit signal input, 1 for triggering all zones alarm, 1 for local broadcasting
◆ With built-in MP3 player, audio files saved on USB flash memory card
◆ With built-in monitor function, can monitor the speakers at each zone
◆ Can save the running program when power failure happens, and auto-resume after power supply recover
◆ Programmable shortcut keys make the operation easy
|
