Local: guangzhou wenbao bank equipment co.,ltd >> Outdoor Medium Size Magnalium Column Speaker

Name:
 Outdoor Medium Size Magnalium Column Speaker
Moble:
 BL-810W BL-820W BL-830W BL-840W
Memo:
 Larger picture
      Previous:  Outdoor Small Size Magnalium Column Speaker
             Next:  Outdoor Bidirectional Magnalium Column Speaker

　Product explanation

点击新窗口打开大图

Model No.
BL-810W
BL-820W
BL-830W
BL-840W
Rated Power
10W
20W
30W
40W
Line Voltage
70/100V
Freq. Resp.
140Hz - 13kHz
Sensitivity
90±2dB
92±2dB
93±2dB
95±2dB
Connection
Black tip： COM     yellow tip： 70V    red tip：100V
Installation
Wall-mount
Speaker (Treble)
2.5”/4Ω/5W x 1pc
Speaker (Bass)
4”/8Ω/10W x 1pc
4”/8Ω/10W x 2pc
4”/8Ω/10W x 3pc
4”/8Ω/10W x4pc
Dimensions
270*150*125mm
420*150*125mm
490*150*125mm
620*150*125mm
Package Size
350*320*220mm
480*320*220mm
550*320*220mm
700*320*220mm
N.W
1.9kg
3.1kg
3.4kg
4.6kg
G.W
4.9kg
7kg
9.1kg
10.7kg



点击新窗口打开大图

Time:2009/9/7 【Print】 【Close】
